Overview

Rotax 400 EFI engine
TTI Independent rear suspension
Visco-Lok 4x4 front differential
MacPherson front suspension
CVT Transmission
Multi-function gauge
Center skid plate
MAX Chassis
Convertible rack/seat system
The XT package offers all the standard Outlander 400 EFI features, PLUS
Cast aluminum rims with aggressive tread Carlisle ACT radial tires
3000-pound [1,361 kg] BRP XL3000 winch with roller fairlead and wired remote winch control
Integrated winch remote storage
Handlebar with wind deflectors
Heavy-duty front and rear bumpers
XT Added features
BRP XL3000 winch
Cast aluminum wheels
Heavy-duty front and rear bumpers
Carlisle 25-inch ACT radial tires
Handlebar wind deflectors
Engine
Type: 400cc, single cylinder, liquid-cooled, SOHC, 4-valve
Bore & Stroke: 91 x 61.5 mm
Net Power: 33 Nm @ 5,750 RPM
EFI System / Carburetor: 46 mm Throttle Body, Siemens VDO injector
Starting System: Electric w/ auxiliary recoil
Transmission: CVT, sub-transmission with high, low, park, neutral & reverse, Standard Engine braking
Drive Train: Selectable 2w/4w shaft driven with Visco-lok front differential
Chassis
Frame: SST
Front Suspension Type: McPherson
Travel: 7 in (178 mm)
Rear Suspension Type: TTI independent
Travel: 8 in (203 mm)
Front Brake: 2 inboard hydraulic discs
Rear Brake: 1 inboard hydraulic disc
Tires/Front: 25 x 8 x 12 in. (635 x 203 x 305 mm)
Tires/Rear: 25 x 10 x 12 in. (635 x 254 x 305 in)
Wheels: Steel
Dimensions
L x W x H (in): 94 x 46 x 45 in
L x W x H (mm): 2.387 x 1.168 x 1.143 mm
Wheelbase: 57 in (1.447 mm)
Seat Height: 35 in (877 mm)
Ground Clearance: 9.3 in (236 mm)
Dry Weight: 668 lbs (303 kg)
Towing Capacity: 1300 lbs (590 kg)
Rack Capacity: 100 lbs (45 kg); 200 lbs (90 kg)
Storage: Rear storage 5.3 US gal (20L) CRS (Convertible Rack System)
Fuel Capacity: 5.3 US gal. (20 L)
Features
Instrumentation: Speedometer, tachometer (bar graph RPM, bottom bar numerical RPM), odometer, trip meter, diagnostic center, gear position, hour meter, engine hour meter, 4x4 indicator, temperature and engine lights, fuel gauge, auto shut off after 15 minutes
Electrical: Prewired for winch
Lighting: 2 fender mounted headlamps (35W) with tail light / brake light
DC Outlet: Lighter type in console, standard connector in the back (15A)
Color(s) available: Yellow, Viper Red, Black
Warranty
Basic: 6 months limited factory warranty
Extended: B.E.S.T. available from 12 to 36 months
Other features
Steel racks with 300-pound (136 kg) capacity
SST frame


Specifications
Engine
Engine Type Single cylinder, liquid-cooled, SOHC, 4-valve
Displacement 400 cc
Bore x Stroke 91 x 61.5 mm
Cylinders Single
Engine Cooling Liquid
Fuel System 46 mm Throttle Body, Siemens VDO injector
Starting System Electric w/ auxiliary recoil
Chassis
Front Suspension McPherson
Front Travel 7 in. (178 mm)
Front Brake Type 2 inboard hydraulic discs
Front Tires 25 x 8 x 12 in. (635 x 203 x 305 mm)
Rear Suspension TTI independent
Rear Travel 8 in. (203 mm)
Rear Brake Type 1 inboard hydraulic disc
Rear Tires 25 x 10 x 12 in. (635 x 254 x 305 in)
Frame SST
Dimensions/Capacities
Dry Weight 668 lbs (303 kg)
Front Rack Capacity (lbs) 100 lbs (45 kg); 200 lbs (90 kg)
Rear Rack Capacity (lbs) 100 lbs (45 kg); 200 lbs (90 kg)
Towing Capacity 1300 lbs (590 kg)
Fuel Capacity 5.3 gal. (20 l)
Ground Clearance 9.3 in. (236 mm)
Machine Dimensions (LxWxH) in. 94 x 46 x 45 in. (2.387 x 1.168 x 1.143 mm)
Wheelbase (inches) 57 in. (1.447 mm)
Drive Train
Drive Train Selectable 2w/4w shaft driven with Visco-lok front differential
Transmission CVT, sub-transmission with high, low, park, neutral & reverse, Standard Engine braking
General
Speedometer Standard
Tachometer Standard
Odometer Standard
Lighting 2 fender mounted headlamps (35W) with tail light / brake light
Colors Yellow, Viper Red, Black
Warranty Basic: 6 months limited factory warranty; Extended: B.E.S.T. available from 12 to 36 months
