MSRP: $1849.00

BIG FUN MADE EASY.


All-new and ready to rip, the TT-R110E is a chip right off the YZ450F block - complete with a nearly indestructible four-stroke engine, class-exclusive four-speed automatic gearbox, electric start and YZ-inspired styling.

Convenient electric starter for effortless starting.
Big fun for the whole family in an all-new package, the YZ-styled four-stroke-powered TT-R110 begs to be ridden by everyone from bigger kids to adults.
A seat height of only 26.4 inches makes this one accessible to most riders, but 7.1 inches of ground clearance and great suspension at both ends mean it can go places.
Class-exclusive four-speed auto-clutch transmission has an easily accessible gear for nearly any terrain.
Engine
Torquey/powerful 110cc air-cooled SOHC four-stroke powerplant is tuned for maximum off-road performance in a wide range of trail conditions.
Compact hemispherical combustion chamber with 9.3:1 compression produces max torque at 4000 rpm, max horsepower at 7500 rpm.
Four-speed gearbox with automatic clutch has the right gear for wherever you ride.
Convenient electric starter for effortless starting.
CDI ignition system is ultra-reliable and never needs maintenance.
Automatic cam chain tensioner means minimal maintenance and longer engine life.
Easy-access, tool-free air filter adds extra convenience during maintenance.
Lightweight exhaust system features quiet, USFS-approved spark arrestor.
Chassis/Suspension
Steel backbone frame ties steering head and swingarm pivot together via a straight line, with the engine mounted at three places for optimum strength and high ground clearance.
31mm fork with high-tech internals including a damper valve with oil lock provides excellent damping, great bottoming resistance and 4.5 inches of smooth travel.
Monocross rear suspension pivoting on a strong, 12mm shaft, along with a gusseted steel swingarm, provide excellent rear wheel control through 4.3 inches of travel.
Die-cast aluminum top triple clamp helps provide light, precise handling and looks great, too.
26.4-inch seat height and 7.1 inches of ground clearance help inspire confident performance on rugged trails.
Front and rear drum brakes deliver strong, dependable stopping power.
14-inch front and 12-inch rear wheels inspire great rider confidence by keeping the seat low and the steering light.
Knobby tires offer superb grip and exceptional wear.
Additional Features
Long, YZ-style seat is low, comfortable and allows easy rider movement.
Team Yamaha–inspired colors, graphics and front and side number plates create styling similar to larger YZ lineup.
Large, folding, cleated footpegs provide excellent footing even in wet or muddy conditions.
Key-type ignition switch deters unauthorized riding.
Engine Specificaions
Type: 110cc air-cooled 4-stroke, SOHC
Bore x Stroke: 51.0mm x 54.0mm
Compression Ratio: 9.3:1
Carburetion: VM16 x 1
Ignition: CDI
Transmission: Constant-mesh 4-speed/wet, multiple disc
Final Drive: Chain drive
Chassis Specificaions
Suspension/Front: Telescopic fork, coil spring/oil damper, 4.5-in travel
Suspension/Rear: Swingarm Monocross®, coil spring/gas-oil damper, 4.3-in travel
Brakes/Front: 95mm drum
Brakes/Rear: 110mm drum
Tires/Front: 2.50-14-4PR
Tires/Rear: 3.00-12-4PR
Dimensions
Length: 61.6 in
Width: 26.8 in
Height: 36.3 in
Seat Height: 26.4 in
Wheelbase: 42.5 in
Ground Clearance: 7.1 in
Dry Weight: 152 lb
Fuel Capacity: 1.0 gal
Warranty
90 Day (Limited Factory Warranty)
Color
Team Yamaha Blue/White
NOTES:
Price and specifications subject to change without notice. Please read your Owner's Manual and all labels before operation.
